ALM-17.3N is a retractable monitor with front 17.3" monitor and back 10.1" monitor for video conference system.
Name: | arthur holm motorised retractable monitors with mic AML-15.6MS |
---|---|
Model No:: | AML-15.6MS |
Type: | screen + microphone motorized Lift |
Item: | Ultra-thin LCD lift with 15.6 inch screen +motorized microphone |
Color: | Aluminum black/silver |
Function: | Presentation |
Material: | Aluminum alloy brushed |
Screen Size: | 15.6 inch screen (16:9) |
Microphone: | conference system mic |
Panel Size: | 615*80*5mm |
Box Size: | 602*71*730mm |
Cutout Size: | 604*73mm |
Resolution ration: | 1080*1920 |
Interface: | HDMI+RS232 I/O+USB+XRL |
arthur holm motorised retractable monitors with mic AML-15.6MS
Keywords: motorised retractable monitors, arthur holm, monitor lift, lifting monitor, conference table monitor, lift 19", motorised LCD, retractable monitor solution, paperless conference system, motorized lift mechanism,
Introduction:
ALM-15.6MS is designed as a advance integration hiding equipment of ultra-thin Monitor Lift with 15.6"
screen + motorized microphone for conference audio video system.
15.6, 17.3 inch Full HD LED Screen for selection to meet the requirment of different monitor size.
Controlled conveniently by touch swith, remote control or central control, the screen could be rasing up form the conference tables automatically throgh the lift driving.
Apart from the screen, the mic Lift also can drive the conference mic working sperately.
Using updated lifting mechanism, makes the monitor lifts up and down faster and quieter.
With 13.3, 15.6, 17.3, 18.5, 21.5, 23.6 inch Full HD screen for selection,
It is widly use in conference system, video conference system, tv conference system, financial analyzing system,
advanced office system,lecture and training room with conference table& computer desk,etc.
Selling Point:
full aluminum alloy finish, orrosion resistant, wear-resistant,smooth surface and not easy to scratch.
Ultra-thin Design, only 8.8cm width of whole product , with 5mm thickness monitor
Motorized lift with 15.6inch FHQ screen + motorized microphone design, to meet the requirment of user's vision and talking
conference system microphone, can working or up and down sperately by motorized control
Motorized by tank chain and mechanical gear, good quality and smooth and quiet when working
Full HD LED Screen, high quality and brings a good viewing
Hidden design to save more space and makes a modern office environment
Ultra --thin monitor and lift body, elegant design and save space
Automatically adjust to 20 degree overturn, adjustable angle could be control to make prefect viewing angle for users
Virtually Silent working with excellent working life.
works smoothly and quietly. Low noise which less than 30db
with protecting function of LCD monitors by cutting the electricity off automatically
Control system: Touch Switch on LCD motorizedLift panel, RF remote control, RS232 AND rs 485 central control..
Power plug and voltage could be changed according to user's requirment
Automatic straighten microphone up function screen lift & mic lift working sperately
Anti-pinching hand protection system for safe.
Detail Parameter:
Item Name | lcd screen + microphone motorized Lift |
Style | Ultra-thin LCD lift with 15.6inch FHD screen+motorized microphone |
Model No. | AML-15.6MS |
Material | Full aluminum alloy drawing finished |
Color | Aluminum black/silver |
Panel Dimension | 615*80*5mm |
Panel Thickness | 5mm |
Box Size | 602*71*730mm |
Cutout Size | 604*73mm |
Monitor | 15.6 inch screen (16:9) |
Resolution | 1080*1920 |
Monitor Overturn Angle | 20 degree |
Data Interface | HDMI+RS232 I/O+USB+XRL |
Control System | touch switch, wireless remote , central control RS232 |
Application | High-class office conference meeting room |
Warranty | 1 year |
